Lopolight Masthead/360-Degree Light - 3NM - Black Housing w/FB Base

Masthead/360-Degree Light - 3NM - Black Housing with FB Base

This white 360-degree/masthead light has a black housing, is horizontally mounted, and has a three-nautical-mile range. The FB base centers the wiring for antenna-type pole mountings. The base provides a screw-down onto the deck solution as well as a from-below mounting. Essentially, the base provides a sleeker, reduced profile.

Features:

• Black anodized aluminum housing


• 0.75m cable is included

Specifications:

• Approved To: COLREG72,EN14744,IEC 60945,IACS E10,USCG,ABS,M.E.D.,DNV,LR


• Mounting: Horizontal


• EAN: 5704438043534


• Min. Feed Wire Gauge: 0.5mm2 AWG22


• Light Color: White


• Visibility: 3NM


• Included In the Package: 1 Navigation light, pre-cabled with 0.75 meter shielded marine grade cable and installation guide


• Materials: Black anodized aluminum 25, PMMA lens, A4 stainless steel screws, Epoxy, Polyurethane


• IP rating: IP68


• Connection: 0.75m cable


• Current Consumption (mA @ 24VDC): 148


• Current Consumption (mA @ 12VDC): 300


• Dimensions Metric: 92.5mm x 36mm


• Dimensions Imperial: 3.6" x 1.4"


• Operating Temperature: -25 degrees C to 55 degrees C


• Operating Voltage: 10-32VDC


• Power Draw (W): 3.6


• Vessel Size: Under 12-20 meters
